EarthQuaker Devices Z-Drive

Offered for sale:

Used EarthQuaker Z-Drive pedal serial number 084.

This pedal is in very good to excellent condition, fully functional and cosmetically showing limited playing time.

Dr. Z states:

The idea of adding a pedal to our line of products was on our shop’s “to do” list for some time. The goal was to release a killer tone machine and stick to the quality, craftsmanship and distinguished tone of our brand. Fortunately for us one of the best pedal companies is just a stone’s throw away; so, we enlisted the talents of Jamie Stillman and EarthQuaker Devices…and the Z-Drive was born.

The Z-Drive starts with an active global EQ and gives you a choice between two distinct sounding preamp channels (via the channel footswitch). The Z-Drive is intended to be a fully integrated preamp pedal capable of adding additional channels to a single channel amp or power amp. The germanium channel uses NOS germanium diodes and can move from a sparkling clean boost to dynamic, open sounding overdrive. The mosfet channel is a more compressed, higher gain overdrive, from edge of breakup grit to blistering distortion. Both gain stages use hi-fi OPA 2134 op amps. Because the signal goes through the EQ first, turning the EQ controls clockwise can increase overall gain/distortion.

With the Z-Drive you essentially get two pedals in one. Between the two channels and the full EQ the Z-Drive will open up a world of possibilities while complementing the tone of your amp.

Specifications:

Controls: Germanium channel: drive, level and cut switch.

Mosfet channel: drive, level and cut switch.

Global EQ: Bass, middle, treble

Channel and Bypass footswitches.

Power: 9-volt DC power supply with a 2.1mm negative center barrel or 9 volt battery.

Dimensions & Weight: 1 1/16″ H, 4 11/16″ W, 3 11/16″ D; 1lbs.

*Please note: we do our best giving descriptions of used pieces. We have found it impossible to describe every mark on an instrument or amp that is not in the "mint" category. Also, what's important to you may not be important to someone else. For example, you may say, "I don't care what it looks like as long as it plays or sounds well." Another person may say, "Body cosmetics are very important to me so tell me about every scratch, nick and blemish." So, please ask the questions that are most important to you. If you ask they will be answered. They are free and there's no limit. Additional photos can also be made available.

This is a specific item that is also being offered for sale in our brick & mortar location. It is possible that it has just been sold. Please ask if it is still available before purchasing.

*It is our policy to require a signature on delivery of all musical instruments. Please let us know if you prefer no signature required when ordering or we will automatically require a signature.

If you prefer your item to be sent without a required signature Imperial Guitar and the selected carrier can no longer be responsible for the security of the package once it has been delivered.
